SPECIFICATIONS
CAPACITY: 3 pans 12” x 14” x 2.5” deep (Pans not included)
OUTPUT CHILLING CAPACITY: +194/+37°F 15 lbs within 90 minutes
OUTPUT FREEZING CAPACITY: +194/0°F 11 lbs within 240 minutes
OUTPUT THAWING CAPACITY:
0°F/38°F 3 lbs within 240 minutes
0°F/38°F 6 lbs within 480 minutes
0°F/38°F 9 lbs within 720 minutes
DISTANCE between shelves: 2.75”
OUTSIDE DIMENSIONS: 23.62” (W) X 23.82” (D) X 15.75” (H)
INTERIOR DIMENSIONS: 13.39” (W) X 14.25” (D) X 10.63” (H)
WEIGHT: 93 lbs
SHIPPING DIMENSIONS: 26” (W) X 26” (D) X 26” (H)
SHIPPING WEIGHT: 110 lbs
HEAT LOAD BTU/HR: 1,850 – 10° F evaporator temperature/104° F ambient
ELECTRICAL SUPPLY:
115-120 V/1 PH/60 Hz
RLA/LRA/MOP: 5/25/11
20 A circuit, # 12 wire required
INSTRUCTION MANUAL
